Roland VP-03 Vocoder

Roland VP-03 Vocoder Overview:

The VP-03 is a miniature version of the VP-330 Vocoder Plus, one of the most popular vocoders ever made. Part of the Roland Boutique series, the VP-03 brings together the worlds of synthesized sound and the human voice, using the latest ACB technology to accurately emulate the sound that made the original so influential. The VP-03 has the VP-330’s vocoder, human voice, and strings sound sources on board, and comes with a gooseneck microphone. And when paired with the optional K-25m Keyboard Unit, you’ve got the authentic VP-330 vibe in a reliable, low-cost setup that’s highly portable. There are new features too, including 16 Chord Memory setups and a Voice Step Sequencer for even more creative potential. Whether you want the classic, electro-infused “talking robot” sound or the expressive power of shaping synth sounds with the human voice, the VP-03 puts it all at your fingertips.

Features:

• Ultra-compact recreation of the iconic VP-330 Vocoder Plus
• Retains the sound, character, and user interface of the original VP-330
• Gooseneck XLR mic included
• New features include Voice Step Sequencer and Chord Memory function for one-finger performance
• High-quality construction with metal front panel
• Highly portable for mobile music making
• Battery-operated (4 x AA) or USB powered
• Built-in powered mini-speaker for instant enjoyment
• Dual ribbon controllers for pitch bend, modulation, and one-touch sound preview
• Compatible with optional K-25m Keyboard Unit and DK-01 Docking Case

Specifications:

• User MemoryChord Memory: 16
• Controllers: VOLUME knob, TUNE knob, Ribbon Controllers C1, C2, PLUG-IN POWER (MIC) switch, C1 MODE switch
• PITCH SHIFT Section: TIME knob, PITCH SET knob, AUTO/OFF/MANUAL switch
• BALANCE Section: DIRECT MIC slider, HUMAN VOICE slider, STRINGS slider
• VIBRATO Section: RATE slider, DELAY TIME slider, DEPTH slider
• VOCODER Section: VOCODER ON/OFF switch, ENSEMBLE switch, LEVEL slider, TONE slider
• HUMAN VOICE Section: MALE 8' switch, FEMALE 4' switch, ENSEMBLE switch, ATTACK slider
• VOCODER/HUMAN VOICE/STRING Common Section: RELEASE slider
• STRINGS Section: STRINGS switch, ATTACK slider, TONE slider
• MEMORY button: 1–16 buttons, PLAY/STOP button
• Effects: ENSEMBLE (chorus)
• Step Sequencer: 716 steps, 16 patterns, 6 notes, Sampling voice (100 ms)
• Indicators: Peak LED, Signal LED
• Connectors: TMIC IN jack: XLR type, PHONES jack: Stereo miniature phone type, OUTPUT jack: Stereo miniature phone type, MIDI (IN, OUT) connectors, USB port: Micro-B type (Audio, MIDI)
• Power Supply: Rechargeable Ni-MH battery (AA, HR6) x 4, Alkaline battery (AA, LR6) x 4, USB bus power
• Current Draw: 500 mA (USB bus power)
• Expected battery life under continuous useRechargeable Ni-MH battery: Approx. 6 hours
• Accessories: Dedicated microphone, Owner's Manual, Leaflet "USING THE UNIT SAFELY", Alkaline battery (AA, LR6) x 4
• Size & Weight:
• Width: 300 mm, 11-13/16 inches
• Depth: 128 mm, 5-1/16 inches
• Height: 46 mm, 1-13/16 inches
• Weight: 940 g, 2 lbs 2 oz

Made in China
