Furman PL-8C-E 10A Power Conditioner with Lights

Furman PL-8C-E 10A Power Conditioner with Lights Overview:

• Family: Classic Series 240V
• Line Voltage: 240 Volts
• Power Requirements: 240 Volts
• Number of Outlets: 11
• Number of Isolated Banks: 2
• Outlet Descriptions: All 11 outlets linearly filtered and surge protected
• Rack Mountable: Yes
• Rack Ears Included: Yes
• Front Panel Meter(s): No
• Front Media Light(s): 2 multi-LED, dimmable lamps
• Control: On/Off switch and light dimmer knob on front panel
• Voltage Regulation: N/A
• Compliance: CE
• Dimensions: 482.6mm W x 266.7mm D x 44.5mm H
• Power Consumption: 12 Watts
• AC Protection: Extreme Voltage Shutdown, Series Multi-Stage Protection, Non-sacrificial protection with zero ground contamination
• Under-Voltage Shutoff: 180V
• Over-Voltage Shutoff: 274V
• Maximum Current Rating: 10 Amps
• Initial Clamping Level: 375 VAC peak @ 3,000 Amps
• Filtration Technology: LiFT
• Filtration Rating: 10 dB @ 10 kHz, 40 dB @ 100 kHz, 50 dB @ 500 kHz
• Power Cord: 3/1.0MM AWG, 2.5M cord w/IEC female to 10A Schuko plug
• Voltage Protection Rating: UL 1449 3rd Edition, 3,000A
• Response Time: 1 nanosecond
• Peak Impulse Current: 6,500 amps
• Rear BNC Connector: Rear rack lamp, 12VAC 500MA max (lamp not included)
