Behringer CMD Studio 4A DJ Controller

Behringer CMD Studio 4A DJ Controllerξ

The Behringer CMD Studio 4A DJ Controller is a four-deck MIDI DJ controller that features a built-in four-channel USB audio interface. It has dual six-inch touch sensitive platters as well as backlit buttons that correspond to what is going on in your software. Each channel has a 100mm pitch fader for pitch bending and control and a 60mm volume fader. The mixer section features a crossfader, a three-band EQ with EQ kill, FX assign, and cue and track load buttons.

The CMD Studio 4A has a total of eight Hot Cue buttons and two FX modules. It supports library navigation, looping controls, and keylock. The CMD Studio 4A is expandable with other CMD controllers.ξ

Behringer CMD Studio 4A Features:

• Highly integrated 4-deck controller with built-in 4-channel USB audio interface.
• Deckadance LE DJ software voucher from Image-Line included.
• Compatible with popular DJ software including Native Instruments Traktor*, Serato Scratch Live*, Ableton Live* and any other MIDI-compatible programs.
• Powerful 4-channel USB audio interface with 24-bit converters and ultra-low latency operation under Windows and OSX operating systems.
• Large 6äó? touch-sensitive high-resolution control platters for precise control.
• Class-compliant MIDI protocol enables DJs to use the CMD Studio 4A with any MIDI software.

Behringer CMD Studio 4A Specifications:

• Output: 4x RCA 1x 1.4" (6.35 mm) TRS Headphone
• \r\r
• Output Impedance: 120 ‘©
\r\r
• Signal to Noise Ratio: 97 dB
\r\r
• Crosstalk: < 80 dB@ 1 kHz
\r\r
• Maximum Output Level: RCA: 8 dBu
\r\r
• Headphones: -4 dBu (18 dBm) @ 32 ‘© loading
\r\r
• Interface: USB 2.0, Type B
\r\r
• Audio Converters: 24-bit/48 kHz
\r\r
• Faders: 2x 3.9" (100 mm) pitch faders, 2x 2.4" (60 mm) volume fader, 1x crossfader
\r\r
• Effects Per Channel: 3-band EQ, EQ Kill, Key Lock, Pitch Control, Auto Looping
\r\r
• Hot Cue: 8x
\r\r
• Compatibility: Any class compliant MIDI software, Mac OS X, Windows
\r\r
• Power Supply Voltage: 100-240 V, 50/60 Hz
\r\r
• Power Consumption: 12 W (Maximum)
\r\r
• Mains Connection: External Power Adapter
\r\r
• Dimensions (W x D x H): 19.8 x 12.5 x 2.3" (50.2 x 31.7 x 5.9 cm)
• Weight: 2.7 kg.
