Roland Octapad SPD-20PRO Digital Percussion Pad

Roland Octapad SPD-20PRO Digital Percussion Pad Overview:

THE LEGENDARY PERCUSSION PAD, UPDATED FOR MODERN PERFORMANCES
Introduced over 20 years ago, the SPD-20 is still treasured by percussionists around the world for its wide-ranging versatility and authentic percussion sounds. Filled with user-requested features and the latest Roland percussion technologies, the OCTAPAD SPD-20 PRO takes performance to the next level while fully retaining the core appeal of the classic SPD-20.

The OCTAPAD SPD-20 PRO offers the famous eight-pad layout, legendary sounds, and rugged durability of the original SPD-20, newly enhanced with more responsive playability, additional sounds and functions, and an updated user interface. Compact and portable, the OCTAPAD SPD-20 PRO delivers everything you need to authentically cover percussion in all music genres and settings, from small groups to large-scale ensembles.

Features

• The original SPD-20 sound set, augmented with all-new percussion sounds for a wider sonic palette
• Includes a broad selection of world percussion, with more than 900 instruments to choose from
• 200 customizable percussion kits, including 100 ready-to-play presets
• Eight cushioned rubber pads provide even and accurate triggering, improved dynamic response, and excellent isolation between pads
• Four external dual-trigger inputs and a dedicated hi-hat control input allow connection of additional pads and pedals, including a kick pad and hi-hat controller pedal to create a mini drum kit
• Dedicated buttons for adjusting sound-editing parameters while performing
• LCD + LED screens with backlights for easy visibility on dark stages
• USB memory port for backing up settings and kit data
• Designed in Japan

Specifications

• Instruments: 900 Instruments Or Greater
• Kits: 200 (Preset: 100)
• Kit Chain: 16 chains (16 steps per chain)
• Power Supply : AC adaptor (DC 12 V)
• Current Draw: 500 mA
• Pads
• Built-in Pads: 8
• * Four external trigger inputs are provided, allowing you to connect Pads.
• Layer
• 2 layers per pad
• 2 layers x 2(Head/Rim) per external Trigger
• Display
• 16 characters 2 line (backlit LCD)
• 7 segments, 3 characters (LED)
• Kit Effects
• Ambience (5 Types)
• Kit EQ
• Kit Comp
• MFX : 3 systems, 38 types
• Connectors
• PHONES Jack: Stereo 1/4-inch phone type
• OUTPUT(L/MONO, R) Jacks: 1/4-inch phone type
• MIX IN Jack: Stereo 1/4-inch phone type
• EXTERNAL TRIGGER INPUT Jack : 1/4-inch TRS phone type x 4
• HH CTRL Jack: 1/4-inch phone type
• FOOT SW Jack: 1/4-inch TRS phone type
• MIDI (IN, OUT) Connectors
• USB MEMORY port: USB A type
• Instrument /Pad Parameters
• Volume
• Curve
• Coarse Tune
• Fine Tune
• Pedal Bend
• Decay
• Output
• Layer EQ
• Pad comp
• Pad Mute Group
• Pad Link
• Accessories
• Owner's Manual
• AC Adaptor

Size And Weight

• Dimensions: 450(W) x 350 (D) x 72 (H) mm
• Weight: 3.7 kg (excluding AC Adaptor)

Made in China
