Zoom M-2 Mictrak Portable Recorder

Zoom M-2 Mictrak Portable Recorder Overview:

Zoom’s M2 MicTrak elevates the work of creators looking to easily record perfect audio. With its innovative X/Y mic capsule design and 32-bit float technology, the M2 MicTrak always gives you great sound in one take.

Features:

• Stereo 32-bit float recorder
• Newly designed stereo X/Y microphones provide unmatched frequency response and clarity
• Body construction and specialized finish to reduce handling noise
• LCD screen with waveform display
• Easy-to-use front panel controls
• Mono mode for ENG application
• Onboard Normalization function
• 3.5mm headphone output
• Includes a newly designed mic clip to mount on a mic stand
• USB Microphone compatible with PC, Mac, iOS, and Android (48 kHz at 24 or 32-bit Float**)
• Use as a USB microphone and record to SD card simultaneously
• Runs on 2 AA batteries* (11 hour battery life)

Specifications:
Inputs
Built-in mic 90º XY stereo format

• Directionality Unidirectional
• Sensitivity −42 dB/1 Pa at 1 kHz
• Maximum sound pressure input 135 dB SPL

Outputs
PHONE/LINE OUT jack

• Connector:  Stereo mini jack
• Maximum output level: 20 ｍW + 20 ｍW (into 32Ω load)
• Output impedance: 10 Ω or less
• Built-in speaker: 500mW 8Ω mono speaker

Recorder
Recording format: WAV

• 44.1/48/96 kHz, 32-bit float
• Stereo/mono
• BWF and iXML formats supported

Recording media

• 4–32GB cards compatible with the microSDHC specification
• 64GB–1TB cards compatible with the microSDXC specification

Display

• 96×64 LCD with backlight

USB
Connector

• USB Type-C
• • Use a USB cable that supports data transfer.

USB Mic

• USB 2.0 High Speed
• 48 kHz
• 24-bit or 32-bit float
• File transfer USB 2.0 High Speed

Power

• 2 AA batteries Alkaline, Lithium, or Rechargeable NiMH
• AC adapter ZOOM AD-17: DC 5 V/1 A
• • USB bus power is supported.

Estimated Continuous Operation Time Using Batteries

• Alkaline batteries About 11 hours
• NiMH batteries (1900 mAh) About 10.5 hours
• Lithium batteries About 22 hours
• Power consumption 5 W maximum
• Dimensions 221.5 mm (W) × 61.9 mm (D) × 59.3 mm (H)
• Weight (including batteries) 204 g
