Denon PMA-1700NE Integrated Amplifier with USB-DAC

₹239,900

● In stockchecking live price…

View on Ooberpad store ↗

Ooberpad announces the availability of the feature-packed Denon PMA-1700NE Integrated Amplifier with USB-DAC - an ultra-high-fidelity integrated stereo amplifier with USB-DAC for High-res Audio. The 1600NE series has been built by both veteran engineers and talented young engineers who have inherited the Denon technologies and expertise that have been cultivated over many years and decades.

With its robust built-quality, unique Denon technologies and functionally sophisticated connectivity, the PMA-1700NE truly is a masterpiece of sound technology. Featuring advanced ultra-high current single push-pull circuit power, Advanced AL32 Processing Plus, and MM/MC phono equalizer, the Denon PMA-1700NE integrated amplifier delivers extraordinary sound quality with precise detail.

Warranty

1-year manufacturer's warranty

Key Features

Engineered with premium Denon technologies, this amplifier drives two channels at 140W
Advanced AL32 Processing Plus delivers the richly detailed sound the artist intended
Wide bandwidth sound from deep bass to detailed highs
DAC Master Clock Design for jitter-free audio reproduction
Digital isolator to eliminate high-frequency computer noise on the USB-B or digital inputs
FL display for source and sample rate indication
Analog AMP Mode switching off digital audio circuitry and display
Direct Mechanical Ground Construction to minimize unwanted vibration
Main transformer with separate power supplies for analogue and digital circuits for maximum audio signal purity
With more than 110 years of audio excellence, Denon products are built to last

Benefits of Denon PMA-1700NE Integrated Amplifier with USB-DAC

Advanced AL32 Processing Plus

Advanced AL32 Processing Plus supports digital audio sources up to high resolution of 384-kHz/32-bit. The algorithms restore information that was lost during the digital recording to ensure detailed playback.

High-power 140W integrated amplifier

Drive your loudspeakers with 140 Watts of power per-channel into 4 Ohms. This integrated amplifier offers compatibility with the widest range of speaker types and impedances for operational stability.

High-precision electrical controls

The PMA-1700NE embraces electrical volume, balance, and tone controls while preserving the analogue feeling of operation. The unique mechanism offers smooth, linear control. A Source Direct function passes by all tone control for purest audio.

USB-DAC supporting 11.2-MHz DSD and 384-kHz/32-bit PCM

PMA-1700NE provides USB-DAC function that supports high resolution audio signals up to 11.2-MHz DSD and 384-kHz/32-bit PCM. These digital signals with suppressed jitter will get passed on to the high quality DAC for an optimal D/A conversion with highest precision.

Where to buy?

Buy the Denon PMA-1700NE Integrated Amplifier with USB-DAC online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad team. We will help you choose better and give you support to help you take the right buying decision in India.

Technical Specifications of Denon PMA-1700NE Integrated Amplifier with USB-DAC

Brand & Model #	Denon PMA-1700NE Amplifier
General	Unit (W x D x H) 434 x 410 x 135mm 17.1 x 16.1 x 5.3in Cabinet Size (W x D x H) 434 x 374 x 135mm 17.1 x 14.7 x 5.3in Net weight 17.6kg / 38.8lb Front (Center): Panel Aluminum Side cover: SECC with 4 straight emboss Side screw: SP: Nickel / BK: Black Rear Panel: SECC t1.0mm Chassis Material: SECC t1.2mm Bottom Layer Single Volume Knob: Aluminum Input Selector: Aluminum Bass/Treble/Balance/ Phono Sel knobs: Aluminum Power button: Aluminum Other knob/button (LOUDNESS, SOURCE DIRECT etc): Mold (Source Direct,Analog Mode,MM/MC) Foot: ABS resin with rigid rib w/Hot stamp (H : 20mm) Heatsink for Power Amplifier: Extruded Aluminum
Power Amplifier Rated Output	70W + 70W (8ohm,20Hz-20kHz,THD0.07%) 140W + 140W (4ohm, 1kHz, THD0.7%)
Speaker Impedance	A or B : 4 ~ 16ohm A + B : 8 ~ 16ohm
Frequency Response	5Hz - 100kHz (0~ -3dB)
Total harmonic distortion	0.01 % (Rated output: –3 dB), 8 ohm/ohms, 1 kHz
Damping Power	100 and over
Input Sensitivity: Phono input	MM: 2.5 mV / 47 kohm MC: 200
RIAA Deviation	20 Hz - 20 kHz ±0.5 dB (MM/MC)
Phono Maximum Input	MM : 130mV / 1kHz MC : 10mV / 1kHz
Input Sensitivity: CD/LINE/RECORDER	125 mV / 19 kohm
Input Sensitivity: Power Amp input	0.85V / 47kohm (EXT. PRE)
Signal to Noise Ratio	PHONO (MM): (89dB) PHONO (MC): (74dB) CD: (107dB)
Tone Control	BASS : 100Hz ±8dB TREBLE : 10kHz ±8dB
Power Consumption	295W At Standby: 0.2W TV autoplay off 0.4W TV autoplay on
Audio Feature	Power Amplifier Circuit: New UHC-MOS Single Push Pull (7) Power Trans: Dual El Core Pre Amplifier Circuit: Variable Gain Preamplifier (OP AMP) Volume: Electric (MUSES 72323) Bass / Treble / Mid / Balance Control: Yes / Yes / No / Yes Type of Tone Control: Electric Controlled by Potentiometer Headphone Circuit: Use Poweramplifier Source Direct: Yes Analog Amp Mode: Yes (button on front panel) Other: 70 DAC Circuit: PCM1795 Digital Filter: Fixed Digital Processing: Advanced AL32 Processing Plus DAC Master Clock Design (Not Support Network Playback): Yes Asyncronous mode (for USB-B input): yes Isolator (for USB-B input): Yes Full Isolation
