Features
| India ’s first micro load UPS. Specially made for the security and surveillance CCTV /Broadcast studio / Medical equipments | |||
| Voltage range of AC 140 - 290V | |||
| ZEB Micro Load Sense system, processor based output load sensing feature, to sense micro power consumption devices | |||
| Backup of more than 3 hours for micro power consumption devices | |||
| Excellent microprocessor control guarantees high reliability | |||
| Advanced 3 Tier battery management system, prolongs battery life by more than 30%. | |||
| Made for extreme Indian Conditions. | |||
| Rogue Equipment Connection proof – can adapt to Generators /Inverters having poor power factor as well as obsolete square wave output. | |||
| LED & Audible alarms for instant alert signals. | |||
| Auto restart while AC is recovering | |||
| Simulated sine wave | |||
| Off-mode charging | |||
| Cold start function | |||
| *(Under testing conditions with 1 DVR without HDD and 2 cameras without IR enabled) | |||
Specifications
| Capacity | 600VA / 360W | |
| Input | ||
| Voltage | 220VAC | |
| Voltage range | 140-300 VAC | |
| Frequency range | 50Hz | |
| Output | ||
| AC Voltage regulation (Batt. mode) | ±10% | |
| Frequency range (Batt. mode) | 50Hz ±1Hz | |
| Transfer time | Typical 4-8ms | |
| Waveform (Batt. mode) | Simulated Sine Wave | |
| Battery | ||
| Battery type & number | 12 V/7Ah x 1 | |
| Typical recharge time | 4-6 hours up to 90% capacity | |
| Indicators | ||
| AC Mode | Green lighting | |
| Battery mode | Green flashing | |
| Fault | N/A | |
| Alarm | ||
| Battery mode | No beep till reach low voltage level | |
| Low battery | Beep every second | |
| Overload | Beep every 0.5 second | |
| Fault | Continuously beeping | |
| Protection | ||
| Full protection | Overload, discharge, and overcharge protection | |
| Physical | ||
| Dimension, D x W x H (mm) | 279 x 101 x 142 | |
| Net. weight (kgs) | 4.2 | |
| Environment | ||
| Humidity | 0-90 % RH @ 0- 40 °C (non-condensing) | |
| Noise level | Less than 40dB | |
| Country of Origin |
China | |
| *Product specifications are subject to change without further notice | ||
| #Load conditions apply. CCTV surveillance system is built up with a DVR , Multi point Power supply, and the Camera array along with the distribution cable , all the above contribute to the main power load on the UPS , hence the Backup time varies according to system setup , make and efficiency of each component in the system. Also the advanced Battery management system protects the full system which has an effect on the back up time. Our results are based on lab test on system having DVR & 2 IR cameras |
||
