Sennheiser XSW2-ME2 Lavalier Wireless Microphone System

Sennheiser XSW2-ME2 Lavalier Wireless Microphone System Overview :

Inspire your audience. High flexibility for those willing to go a step further. XS WIRELESS 2 grows with your demands by offering an intuitive LCD display for more manual options and 12 compatible channels in a stable UHF band, withstanding tougher live stage conditions.

The XS WIRELESS 2 LAVALIER MIC SET is an easy to use all-in-one wireless system for presenters and moderators, excellent for a powerful and inspiring presentation. The set includes a stationary receiver for quick set-up and hassle-free handling, as well as a lightweight bodypack transmitter and an unobstrusive clip-on microphone. Metal receiver housing and rackmount kit included.

Features :

• Unobstrusive clip-on microphone for hands-free operation and compact bodypack transmitter
• True diversity receiver with metal housing
• External antennas
• Automatic frequency management and synchronization via remote channel for easy setup
• Fully tunable over a wide range of UHF frequencies
• Rackmount kit included
• Up to 12 compatible channels

Contents included :

• 1 receiver EM-XSW 2
• 1 bodypack transmitter SK-XSW
• 1 lavalier microphone ME 2-2
• 1 power supply NT 12-5 CW
• 2 AA batteries
• 1 rackmount kit
• 1 pouch
• user manual

Specifications :

Receivers

• Dimensions approx. 200 x 42 x 127 mm
• Weight approx. 680g
• Power supply 12 V DC nom. / 300 mA

Transmitter

• Dimensions approx. 71 x 96 x 28 mm
• Weight approx. 95g
• Operating time approx. 10 hrs

Microphone Condenser

• Frequency response : 50 to 16,000 Hz (–3 dB)
• THD, total harmonic distortion :  ≤ 0.9%
• Pick-up pattern :  Omni-directional
• Signal-to-noise ratio :  ≥ 103 dBA
• RF output power : 10 mW
• Switching bandwidth up to :  24 MHz
• Modulation  : Wideband FM
• Output voltage :  '1/4“ (6.3 mm) jack socket (unbalanced): +6 dBu, XLR socket (balanced): +12 dBu
• Diversity reception :  True Diversity
• Frequency : 8 frequency banks, each with up to 12 factory-preset channels
• Frequency range A : 548-572 MHz, GB: 606-630 MHz, B: 614-638 MHz, C: 766-790 MHz, D: 794-806 MHz, E: 821-832 MHz, 863-865 MHz, K: 925-937.5 MHz
• Sensitivity :  < 3 μV at 52 dB(A)rms S/N
• Squelch : switchable from 3 dBμV to 28 dBμV (via Pilot Tone)
• Synchronization :  2.4 GHz, Low Power OQPSK (only active during synchronization)
• Adjustment Range :  Transmitter 0 to -30 dB, adjustable in 10 dB steps
• Audio adjustment range :  40 dB, adjustable in 5-dB steps
• Line / Mic level :  20 dB, switchable
• Temperature Range operation : 0°C to +40°C, storage: –20°C to +70°C
• Receiver Principle double superheterodyne

Frequency Ranges  :

• XSW2-ME2-A : 548-572 mhz
• XSW2-ME2-C : 766-790 mhz

Made in Germany
