Parasound HINT 6 Halo Integrated Amplifier
From the house of Ooberpad arrives the power-packed Parasound HINT 6 Halo Integrated Amplifier. Parasound's award-winning Halo Integrated Amplifier would seem to be a hard standard to meet. But Parasound's new HINT 6 is an improved version of the globally renowned Halo Integrated Amplifier. After the original Halo Integrated Amplifier, hit the market, it quickly gained a popular name for itself - "HINT" in the Parasound community, and that name is now adopted in the new model as the HINT 6. The remarkable sonic quality and musicality of the original Halo Integrated (HINT) carry on in the HINT 6. The new model is feature-packed with Burr-Brown volume control with easy-to-read front panel display. It is also packed with an upgraded USB receiver along with the plug-and-play functionality for Windows and Mac, a second optical input, increased phono gain, superlative channel separation, and some high-value refinements to its aesthetics.
Warranty
1-year manufacturer's warranty
Key Features:
- Burr Brown analog resistor ladder volume control
- Dimmable front panel volume display
- Updated USB receiver is Plug and play with Windows 10 and MAC
- An additional optical input (2 total)
- Ball bearing supported solid aluminum volume knob
- Programable default turn on volume setting
- Favorite volume memory with remote control button
- Increased phono stage gain for lower output cartridges
- Improved Left/Right channel separation and balance tracking
- Updated cosmetics with subtle gold highlights
Preamp and DAC Features:
- ESS Sabre32 Reference DAC (ES9018K2M)
- Asynchronous USB 2.0 supports PCM up to 384kHz/32-bit
- USB input decodes Native DSD64, DSD128, DSD256 and DoP DSD
- Coax and optical inputs accept PCM up to 192kHz/24-bit
- Analog bass management with high & low pass crossovers
- Home theater bypass input for surround sound integration
- Front panel subwoofer level control
- Dedicated high current headphone amplifier (TI TPA6120)
- Phono input for MM, MC and MI with 100 Ω or 47k Ω load
- Front panel Aux input with automatic +12 dB gain stage
- 5 pairs RCA line level Analog inputs
- 1 pair XLR balanced Analog input
- Balanced XLR and RCA left and right preamp outputs
- 1 balanced XLR and 2 RCA subwoofer outputs
- Bass & treble controls with relay bypass from remote or front panel
- Rear panel IR input and IR loop output jacks
- 12 Volt trigger output
- Back-lit remote control with discrete buttons
- 0.5w standby power consumption meets Energy Star & EU specs
Power Amp Features:
- 160 Watts x 2 @ 8 Ohms (RMS, both channels driven)
- 240 Watts x 2 @ 4 Ohms (RMS, both channels driven)
- Power amp circuit topology designed by legendary John Curl
- Direct amplifier input to bypass preamp section
- High bias class A/AB operation
- Oversized shielded toroid power transformer
- Dual-mono power supply and power amplifier
- 40,000uF power supply filter capacitance
- Matched JFET input stages and MOSFET driver stages
- 12 high voltage/high current bipolar output transistors
- Heavy-duty 24k gold-plated 5-way speaker binding posts
Where to buy?
Buy Parasound HINT 6 Halo Integrated Amplifier online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad.com team. We will help you choose better and will give you all the support you need to take the right buying decision in India.
Technical Specifications of Parasound HINT 6 Halo Integrated Amplifier:
| Brand & Model # | Parasound HINT 6 |
| Power Output - Both channels driven |
(0.9% THD, 20 Hz - 20 kHz) 180 watts x 2 @ 8 Ω RMS 270 watts x 2 @ 4 Ω RMS |
| Current Capacity | 45 amps peak per channel |
| Frequency Response |
110 Hz - 100 kHz, +0/-3 dB 20 Hz - 20 kHz, +0/-0.5 dBB |
| Total Harmonic Distortion (THD) |
< 0.01 %, average listening levels < 0.05 %, 160 watts x 2 @ 8 Ω |
| Interchannel Crosstalk |
> 70 dB at 20 kHz > 78 dB at 1 kHz |
| Signal to Noise Ratio - IHF A-weighted |
Line in: - 103 dB (input shorted) Digital in: - 106 dB |
| Power Amplifier Stage Sensitivity |
1 V at Bypass/Amp In for 28 V at Speaker Out Total Amp Stage Gain: 28 dB |
| Phono Stage Sensitivity / Input Impedance |
MM: 41 dB / 47 k Ω MC: 54 dB / 47 k Ω or 100 Ω |
|
High & Low Pass Crossover Slope |
12 dB per octave |
| Supported DAC Sampling Rates |
USB: up to 384 kHz / 32-bit PCM DSD Native: DSD 64, DSD 128, DSD 256 DSD over PCM (DoP) at 384 kHz |
| S/N Ratio - Phono Input |
MM > 80 dB (shorted, IHF A-weighted) MM > 70 dB (shorted, unweighted) MC > 67 dB (shorted, IHF A-weighted) MC > 55 dB (shorted, unweighted) |
| Coax/Optica | up to 192 kHz / 24-bit PCM |
| Digital to Analog Converter |
ESS Sabre32 Reference ES9018K2M 384 kHz / 32-bit |
| USB 2.0 Controller | Savitech SA9227, 384 kHz / 32-bit |
|
Headphone Amplifier |
Texas Instruments TPA6120A Output Impedance 10 ohms |
| High & Low Pass Crossover Slope | 12 dB per octave |
|
Supported DAC Sampling Rates |
USB: up to 384 kHz / 32-bit PCM DSD Native: DSD 64, DSD 128, DSD 256 DSD over PCM (DoP) at 384 kHz Coax/Optical: up to 192 kHz / 24-bit PCM |
| Digital to Analog Converter |
ESS Sabre32 Reference ES9018K2M 384 kHz / 32-bit |
| USB 2.0 Controller |
Savitech SA9227, 384 kHz / 32-bit |
| Headphone Amplifier |
Texas Instruments TPA6120A Output Impedance 10 ohms |
| XLR Pin Identification |
1 = Ground (Shield) 2 = Positive 3 = Negative (Return) |
| Input Impedance |
Unbalanced: 24 k Ω Balanced: 100 k Ω per leg |
| Preamplifer Output Impedance | Unbalanced: 100 Ω Balanced: 470 Ω per leg |
| Dimensions |
Width: 17-1/4" (437 mm) Depth: 16-1/4" (413 mm) Depth, with cables 17-1/4" (437 mm) Height, with feet: 5-7/8" (150 mm) Height, without feet: 5-1/4" (133 mm), 3U |
| Net Weight |
33 lb. (15 kg) |
| Power Requirement |
Standby: 0.5 watts Idling power: 70 watts Maximum: 750 watts 110-125 VAC 60 Hz or 220-250 VAC 50 Hz AC mains voltage is set on rear panel |
