The KA-10 system includes KA-10R, KA-10T (KA-8TH) , KAC50X / KAC150 cable, TG-10CH2, shoe mount adapter, and CM-201 microphone. It is designed for both professional and consumer video camera. The CM-201 provides omni-directional pick up pattern to expand the coverage to mike a meeting.
- Lithium battery can goes for 14 hours which is useful for travel.
- UHF PLL 16 selectable frequency can render multi system application.
- Over 60 meter operation distance virtually meets all kinds of application.
Specifications:
- Internal Microphone: Omni-directional Condenser Microphone
- Frequency Preparation: PLL Synthesized Control
- Carrier Frequency Range: 502~960 MHz
- 3x Frequency Range: 856.100 - 864.900 MHz (F band)
- 606.500 - 629.900 MHz (U band)
- 721.500 - 748.375 MHz (G band)
- 658.125 - 678.500 MHz (D band)
- 487.125 - 506.500 HHz (I band)
- 502.000 - 694.000 MHz (T band)
- RF Outputs: 10mW
- Stability: ±10kHz
- Frequency Deviation: ±48kHz
- LED Display: Channel
- Controls:
- Power On/Off, Channel selection,
- Volume control
- Spurious Emissions: <-50 dBC
- Audio Frequency Response: 40~18,000 Hz
- Microphone input connector: 1/8” Mono Phone Jack
- Battery life: 14 hours typical
- Battery: Lithium cell (3.7V, 1300mAh)
- Dimension(mm): 54mm(W)* 17mm(D)* 99mm(H)
