Parasound Zamp v.3 Two Channel Zone Amplifier
The Parasound Zamp v.3 Zone Amplifier is the third generation of one of the world’s most popular and proven audio amplifiers. It has been designed for a wide variety of applications, including multi-room, multi-zone installations, desktop audio, PC-Mac audio, bedroom or den systems. The versatility of the Zamp v.3 allows many connection and configuration options.
Warranty
1-year manufacturer's warranty
Key Features:
- 45 watts per channel into 8 Ω
- 60 watts per channel into 4 Ω
- 90 watts bridged into 8 Ω mono
- Fully discrete circuitry with Toroid power transformer
- Low heat design
- Headphone jack
- Indicators for AC present and channel operating status
- Automatic on/off by 9 - 12 V trigger
- Gold-plated RCA input jacks and looping line output jacks
- 5-way speaker terminals
- Compact chassis; 1 rack space high
- Rack mount kit sold separately
Benefits of Parasound Zamp v.3 Two Channel Zone Amplifier:
Perfect For Compact Systems
Like all Parasound Z-series components, Zamp uses a standardized "half-width" rack-mount chassis that is just 1 rack space (1-3/4 inches) tall and 9-1/2 inches wide, half the width of a conventional audio component. This size is perfect for a compact bookshelf audio system or two-abreast in a standard 19-inch professional equipment rack. The amplifier's small size also makes it ideal for unconventional and space-limited applications, including multi-room / multi-zone installations, PC and desktop audio, and bedroom or den stereo systems. This product is truly a custom installation problem solver.
Fully Discrete, Audiophile-Quality Circuitry
Unlike other compact amplifiers, which typically employ low-cost single-chip IC amplifier modules, the Zamp v.3 uses fully discrete, direct-coupled DC servo circuitry, high speed bipolar output transistors, and a massive, high quality toroid power transformer. In addition to its 2 x 45 watts, 8-ohm rating (20 Hz - 20 kHz, both channels driven), Zamp v.3 delivers 60 watts per channel with 4-ohm loads, or can be bridged to provide over 90 watts mono into 8 ohms.
Where to buy?
Buy Parasound Zamp v.3 Two Channel Zone Amplifier online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad.com team. We will help you choose better and will give you all the support you need to take the right buying decision in India.
Technical Specifications of Parasound Zamp v.3 Two Channel Zone Amplifier:
| Brand & Model # | Parasound Zamp v.3 |
| Continuous Power Output |
45 watts RMS x 2, 20 Hz - 20 kHz, 8 Ω, both channels driven 60 watts RMS x 2, 20 Hz - 20 kHz, 4 Ω, both channels driven 90 watts RMS x 1, 20 Hz - 20 kHz, 8 Ω, minimum impedance |
| Current Capacity | 12 amperes peak per channel |
| Frequency Response |
5 Hz - 100 kHz, +0/-3 dB |
| Total Harmonic Distortion |
< 0.07 % full power < 0.02 % typical levels |
| IM Distortion | < 0.05 % |
| Dynamic Headroom | 1.5 dB |
|
Inter-Channel Crosstalk |
80 dB at 1 kHz; 60 dB at 20 kHz |
| Input Sensitivity |
600 mV; 1.5 V for full output |
| Input Impedance |
33 k Ω |
| S/N Ratio |
116 dB, input shorted, IHF A weighted |
| Dimensions |
8-1/2 w x 1-3/4 h x 10 d, 2 h with feet |
| Net Weight |
Net: 7 lbs. (3.17 kg) |
