Parasound ZoneMaster 4 DAX Four Zone DAC
Ooberpad brings you the Parasound ZoneMaster 4 DAX Four Zone DAC. The Parasound ZoneMaster 4 DAX is a single chassis unit that achieves superior DAC performance by using four premium 192kHz/24-bit ESS DACs when using an optical or coaxial connection. In addition to the ESS DAC, each Zone has premium analogue crossovers with level controls and outputs for full-range stereo, high-pass stereo, full-range mono, high-pass mono and an 80-Hz low-pass mono subwoofer output. Each zone also has an audio-triggered 12V output to activate additional equipment such as amplifiers and cooling equipment. Parasound's own 2-, 4-, 6- and 12-channel ZoneMaster amplifiers have independent trigger inputs for each zone making them a perfect companion to the 4 DAX.
Warranty
1-year manufacturer's warranty
Key Features:
- Four Independent DACs in a single chassis
- 192kHz/24bit ESS Sabre DAC ICs
- Level controls for all channels
- Hyperstream™ jitter eliminator
- 3 Volt high gain outputs
- Optical and coaxial digital inputs
- Indicators for digital input signal lock and analog audio output
- 12V trigger output for each zone with turn off delay
- All crossovers are 80Hz and 18dB /octave
- Full range stereo outputs
- Full range mono outputs
- High pass stereo outputs
- High pass mono outputs
- Low pass mono subwoofer outputs
Benefits of Parasound ZoneMaster 4 DAX Four Zone DAC:
A Value Added Alternative
The Parasound ZoneMaster 4 DAX dramatically reduces the rack space and clutter that would have accompanied four separate DACs, four crossovers, plus power supplies and cables, and greatly reducing the time and cost of installation. While the Sonos Connect® traditionally competes in the retail marketplace, Parasound's 4 DAX creates a profitable value-added alternative for the custom installation industry.
Where to buy?
Buy Parasound ZoneMaster 4 DAX Four Zone DAC online at the best price in Mumbai, Delhi, Bangalore, Chennai and all across India. Enjoy expert, prompt and courteous customer service from the Ooberpad.com team. We will help you choose better and will give you all the support you need to take the right buying decision in India.
Technical Specifications of Parasound ZoneMaster 4 DAX Four Zone DAC:
| Brand & Model # | Parasound ZoneMaster 4 DAX |
|
Frequency Response (analog output) |
10 Hz - 20 kHz, +0/-0.5 dB |
|
Total Harmonic Distortion |
0.009% |
|
Interchannel Crosstalk |
84 dB at 20 kHz |
| Audio Output Level |
3.0 Volts RMS |
| S/N Ratio |
> 100 dB, IHF A-weighted Supported Sampling Rates (digital input) Up to 192 kHz / 24-bit PCM |
|
Digital to Analog Converter |
ESS Sabre ES9023 |
| Crossover Frequency (high and low pass) | 80Hz and 18dB /octave |
|
DC Trigger Output |
12 Vdc, 50 mA per zone |
|
AC Power Requirement |
10 Watts maximum 90-250 VAC 50/60 Hz |
| Dimensions |
Width: 17.25" (437 mm) Depth: 14.25" (362 mm) Depth: 16" (369 mm) with cables connected Height, with feet: 2.5" (105 mm) Height, without feet: 1.75" (44.5 mm), 1U |
| Weight | Net: 11 lbs (5 kg) |
