Blackmagic Design Blackmagic Audio Monitor 12G G3
- Dual-Subwoofer Design
- SMPTE 2110 Input Capabilities
- Class-D Amplifiers
- 12G-SDI, AES/EBU, and Analog Inputs
- SDI Loop Out and HDMI 2.0 Output
- LCD Display and Audio Level Meters
Monitor your audio with the 1 RU Blackmagic Audio Monitor 12G G3 from Blackmagic Design. Featuring a dual-subwoofer design with extrawide-range speakers, the audio monitor is equipped with Class-D amplifiers. The upgraded G3 version supports the new SMPTE 2110 input for improved broadcast integration. It features a 12G-SDI input, a balanced XLR analog audio input, a balanced AES/EBU digital input audio, HiFi audio inputs, and an HDMI 2.0 output. The front panel features multicolored audio level meters and a built-in LCD for monitoring video sources.
Technical Specifications:
|
Panel Type |
LCD |
|
Display Size |
2.2" |
|
Resolution |
320 x 240 |
|
Touchscreen |
No |
|
USB I/O |
1 x USB-C Female Input |
|
Video I/O |
1x HDMI 2.0 Output 1x BNC (12G-SDI) Input 1x BNC (12G-SDI) Loop Output |
|
Audio I/O |
1x XLR 3-Pin AES3/Line Input 2x XLR 3-Pin Input 2x RCA Input 1x 1/4" Headphone Output |
|
Other I/O |
1 x RJ45 10G Ethernet 2110 IP Input |
|
Video Resolution |
DCI 4K at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 UHD 4K at 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 DCI 2K at 23.98, 24, 25 2KPsF at 23.98, 24, 25 1080p at 23.98, 24, 25, 29.97, 30, 47.95, 48, 50, 59.94, 60 1080PsF at 29.97, 30 1080i at 50, 59.94, 60 720p at 50, 59.94, 60 525i at 59.94 625i at 50 |
|
Compliance |
SMPTE 295M SMPTE 292M SMPTE 296M SMPTE 424M SMPTE 425M-A, 425M-B SMPTE 2081-1 SMPTE 2081-10 SMPTE 2082-1 SMPTE 2082-10 SMPTE 2110-20 SMPTE 2110‑21 SMPTE 2110‑30 SMPTE 2110‑40 SMPTE 2084 SMPTE 2108‑1 |
|
Sampling Rate |
Audio: 96 kHz / 24-Bit Video: 4:2:2, 4:4:4 |
|
Wireless |
Yes |
|
Power Source |
AC Input |
|
AC Input Power |
100 to 240 VAC, 50 / 60 Hz |
|
Power Consumption |
55 W |
|
Operating Temperature |
32 to 104°F / 0 to 40°C |
|
Operating Humidity |
0 to 90% |
|
Storage Temperature |
-4 to 113°F / -20 to 45°C |
In the Box:
- Blackmagic Design Blackmagic Audio Monitor 12G G3 (1 RU)
- PPM and Loudness Scale Sticker Set
- Limited 1-Year Manufacturer Warranty
